1020371 Bearing Body MEKA MB-S 2.0 m³

A bearing body (a bearing housing or bearing bracket) plays a key role in single-shaft concrete mixers, ensuring they work well in harsh conditions.  The housing is designed to install a bearing inside it, resulting in a bearing assembly (bearing support).It supports the horizontal mixing shaft at both ends, keeping the mixer paddles in line. Hence, they turn quickly through thick and rough concrete mixes. Offering a firm base impacts the radial and axial loads that push on the shaft, which stops it from bending and helps the equipment last longer.

One key advantage of the bearing body is its ability to dampen vibrations. High-speed shaft rotation can cause unwanted vibrations, hurting product quality and wearing down nearby parts faster. A strong bearing housing cuts down these vibrations a lot, making the whole system more stable. Also, the bearing body has tough seals that keep out dust, moisture, and harmful bits—a common problem in concrete mixing. These seals are crucial to keeping the bearings in good shape and lowering the chance of early breakdown.

Maintenance is another area where quality housing shows its value. With easy-to-access grease points and clear spots for checks, the bearing body makes routine care simple by helping you grease or swap out bearings. This design reduces idle time and boosts output by keeping your single-shaft concrete mixer working at its best.

Crafted from rugged materials with skilled workmanship, the bearing body is designed to last in harsh work environments. It provides steady, dependable mixing results in significant construction jobs or smaller operations. Adding a top-quality bearing body to your single-shaft concrete mixer is a smart way to boost productivity, cut repair expenses, and make your equipment last longer—an upgrade that proves its worth on every job.

Techincal Specs:

  — Article: 1020371
  — Product type: Bearing Body

  — Execution material: Cast steel SFERO

  — Steel grade: GGG50 / EN-GJS-500-7

  — Standart: EN 1563-2011

  — Hardness: 170-230 HBW

The kit includes:

  — 1020371 Bearing body: 1 pcs

  — 1002305 Countersunk bolt DIN 7991 / M16x60: 6 pcs

  — 1002399 Spring washer DIN 127 - 17: 6 pcs

  — 1002330 Hexagonal nut DIN 934 / M16: 6 pcs

  — 1002795 Grease nipple H1 / M10x1: 2 pcs

Dimensions:

  — Length: 495 mm
  — Width: 490 mm
  — Height: 266.5 mm
  — Weight: 122.0 kg

  — Mounting kit weight: 1.12 kg

  — Total weight: 123.12 kg

Important notes:

  — The price is for 1 unit with fasteners

  — Minimum order quantity: 2 pcs
